Future Automation FSE90 Motorised Swivel Flat Screen TV Wall Mount
The FSE90 from Future Automation is designed for screen sizes 23" to 40" or with a maximum width of 1000 mm. The motorised TV mount provides a full 90 degree swivel action in either direction and comes complete with an IR remote control. The FSE90 can accommodate Vesa mounting patterns up to 300 x 300 and there is even a 400 x 400 adapter plate meaning that the FSE90 can support larger screens up to 50" however customers will not be able to achieve full 90 degree swivel.
Design Features
- Sophisticated electronics allow for a favourite viewing position to be programmed via the IR remote control.
- Mechanism allows up to 560mm [22.0] extension of screen centre from wall.
- All the power and signal cables for screen and mechanism can be concealed within the bracket.
- Mechanism can be reversed from a left to a right - handed or from a right to a left - handed bracket simply and quickly during the installation process.
- Super quiet and smooth action from parallel to wall out to 90 maximum movement.
| FSE90 Specifications |
|---|
| Screen Size | Up to 22" - 42" |
| Max Hole Spacing | 300mm x 300mm (400 x 400 plate available) |
| Max Weight Hold | 30kg |
| Max Screen Dimensions | 1040mm wide |
| Articulation | 0 to 90 degrees Clockwise or Anti Clockwise |
| Mechanism weight | 13kg |
| Control | IR Remote, switch control & RS232 |
Download Information
Technical Picture & Dimensions of the FSE90 Electric TV Wall Mount
YouTube Video Of The FSE90 In Action
